Ek Turbo Kit
Ek Turbo Kit
Couldn't load pickup availability
patent pending
Please allow 3/4 weeks to allow us to build and ship your kit. All tracking information will be forward to the email you leave at check out: A authorization form will be forward to your email 1-3 days please be alert.
The kit includes:
-
- Pulsar Dual ball bearing
- Pulsar 60mm Wastegate
- Pulsar 50mm Blow Off Valve
- Pulsar Oil Drain flange 10an
- Dc5creations turbo Manifold
- Dc5creations Intercooler 600/800hp
- Dc5creations Intercooler mounts
- Dc5creations Steel OE oil pan w/ 10an bung welded on
- Dc5creations intercooler piping 2.5 inch specific to this chassis. 4 aluminum piping, couplers and clamps.
-
- Turbo Oil feed line with heat sleeve
- Heat sleeve Turbo drain Line
- Intake temp sensor bung Adapter
- separately
- 3 stainless 90 degree push lock fitting. 3 feet of hose push lock hose
- One Y push Lock fitting
- Turbo Blanket
- Velocity Stack
Items you will need to finished completing the kit . what we recommend that has work for us over the years.
- Under 600hp clutch master fx400
- Over 600hp clutch master 725 twin disc
- Fuel system
- 2150 injectors from FCI or alpha injectors better to have enough fuel and not worry. Can you go smaller ? Yes, but what has been successful for us.
- 535 walbro Fuel pump. Can you go 450 definitely if you already have it but again one thing you don’t wanna do over and over is fuel system.
- Catch can not needed but definitely helps
- Intercooler piping will ONLY work with rbc manifold
- Fuel Pump relay harness
Pulsar product are directly ship through them. Please allow 2/3 weeks for all your items to be all delivered.
Pulsar items are Turbo, wastegate, blow off valve and drain bung.
DC5creations product will also all ship 2/3 weeks. We will email you all shipping information please leave a good email to contact you at check out.
. If this eta is too long for you PLEASE DO NOT ORDER.
Items sold for off-road
ALL SALES ARE FINAL
